Many factors can dry the printer heads and nozzles clogged with dust and dirt. It is very normal for nozzles to be clogged over time and reduce print quality. Therefore, a thorough cleaning is mandatory from time to time, and the printhead solves all the quality issues and keeps the printer working smoothly. So, this blog focuses on how to clean Setup.brother.com heads.
To clean Brother printer heads, you must conduct a print Quality check by running the ink self-cleaning function. If the printhead still causes some problems, manually clean it with a syringe and custom tubing to flush the cleaning liquid properly through the nozzles.
How To Clean Brother Printer Heads?
Here are two methods through which you can clean Brother print heads: by following self-cleaning and manual Cleaning.
How To Clean Printer By Self-Cleaning?
The self-cleaning function allows you to directly maintain your printer without needing physical effort to open or handle it. To perform this method, you first need to run a print quality check to make you understand the issue.
To do this, follow the given steps:
- If your Brother printer model has a separate ink key on the control panel, then push it. If not, go to the Menu and use the Up and Down arrows to find the ink. And then press OK.
- Then, use the Up and Down arrows to navigate Test Print and press OK.
- Lastly, use the Up and Down arrows to select Print Quality. Now press OK and then Start.
- Then, the print quality feature will start and produce a printout to detect which ink color has quality issues.
How will you clean the Brother print head using the self-cleaning function? You need to find ink on your Setup brother com to perform the cleaning function. Follow the given steps:
- If your model has separate ink on the key control panel, then push it. If not, go to Menu and use the Up and Down arrows to find ink. Then press OK.
- Again, use the Up and Down arrows, find Cleaning, and press OK.
- Lastly, use the Up and Down arrows, select the color you need to clean, and press OK.
However, depending on the nozzle clogging, you may have to perform the ink cleaning several times. This method may eat up your ink, but effective in cleaning the print heads.
How To Clean The Brother Printer Head Manually?
The self-cleaning function may not be sufficient. The ink build-up may be too much, and printhead blockage is the same. Hence, in such a situation, you will have to clean the Brother print heads manually. Visit brother.com support
Prepare The Printer Head For The Manual Clean Up
Before starting the cleaning, you have to prepare the printer. For this, you need to open the top of the printer using the side opening to put your finger to use the ink cartridge holder.
Then, insert a piece of folded paper into the upper lid with a switch slot from the top of the printer opening. It tricks the printer so that it thinks the top lid is closed.
Next, try to print a document from your computer. When the ink cartridges slide toward the center of the printer, disconnect the power cord from the rear of the printer. The process will free the printer compartment and let you move the cartridges from side to side.
Moving forward, remove the ink cartridges fully from the printer. Use a plastic bag to place the ink cartridge to prevent ink from drying. Lastly, take a paper towel, fold it, and gently put it inside the ink cartridge housing unit. The towel will absorb the fluid, excess ink, and debris during Cleaning.
Finally, Clean The Printer Head
For Cleaning, you will need a printhead cleaning solution, syringe, and custom tubing. When you remove the ink cartridges, ink nozzles will be visible. Using latex gloves would be good for preventing ink stains on your hands.
Then, use the printhead cleaner ( you can also use 50% distilled water and 50% isopropyl alcohol) and slowly put 5-10 drops directly on the top of the nozzles. Then, take a Q-tip and gently clean and dry the nozzles from the outside.
Take cleaning fluid in a syringe and attach one end of the tubing to the syringe and another to the nozzles you are cleaning. Now, slowly start flushing out the ink nozzle.
Now the paper towel will work. When the blockage is released from the nozzles, the fluid will drop onto the paper towel. So, you have completed the cleanup successfully. Visit at- support brother com
After you have completed the cleanup, ensure all the components are dry before reinstalling them. Then, again run the Printer Quality Check. Finally, you’ve learned how to clean Brother printer heads.
How To Set The Brother Printer Head?
The Brother printer may get misaligned over time; this often results while performing a printhead cleaning. Your printer might still be printing, but the output will be faded. But in many cases, the printer may not print at all and will produce only monochrome pages.
To do alignment of print head:
- If your Brother printer model has a separate ink key on the control panel, then push it. If not, Select Menu and use the Up or Down arrows until you find ink. Then, press OK.
- Then, use the Up and Down arrows to find “Improve Print Quality” and “Alignment.” And then press OK.
- Next, use the Up and Down arrows to show the paper size you need to align.
- Once you select the paper size, select Basic alignment or Advanced alignment.
