Solar Water Pump

avatar
Kenbrook Solar
Solar Water Pump

Solar Water Pump

The solar water pump also know as solar pumping system, solar submersible pump or solar pump, a water lifting system powered with electricity generated by solar panel.

(इस पेज को हिंदी में पढ़े: सोलर वाटर पंप)

Solar pump directly connects with solar panel through a mppt solar pump controller. Whenever sunlight drops on solar panel, solar submersible pump starts lifting the water from ground.

Working diagram of solar water pump

Working diagram of solar pumping system

There is no electricity required to run this solar pump. Even using solar power pump is more economical where grid electricity is not available.

These pumps mostly uses by farmers for irrigation of farming land and horticulture farms. Solar pump can be use for fountain, swimming pool pump, water circulation pump, mono-block home pump and other similar applications.

Major components of Solar Pump

  • Solar panel which generate power.
  • Controller which controls the system.
  • Motor pump to lift the water.
solar submersible pump equipment

solar submersible pump equipment

Types of solar pump

There are many types of solar pump, but only two types are most successful. One is submersible solar pump and another is surface pump. Both pump come in DC and AC technology.

Solar Submersible Pump

Where the depth of water level is more than 15 meter, submersible pump is recommended. This pump keeps inside the water and lift it out.  Solar submersible pump is the most selling pump in India as the depth of water level is very low in maximum areas.

Solar Surface Pump

If the depth of water is less than 15 meter and you want to lift to ground or above the ground level, Solar surface is recommended.

Other Technologies' Solar Pump

We have three technologies to power your solar surface water pump (AC/DC) and solar submersible water pump (AC/DC). The detailed description of technologies is mentioned below:

  1. Solar pump VFD Drive
  2. Hybrid Solar PV pump (Solar power + Grid electricity + Battery)
  3. On grid solar PV pump (With Net Metering)

Solar pump VFD drive

VFD drive is a solar solution for farmers. Solar pump VFD drive converts your existing water pump into solar pump. This technology is becoming famous day by day. Because there are shortage of electricity in rural area and through VFD drive farmers can operate there pumps even when there is no grid.

Hybrid solar water pump

In hybrid solar pump, there are three power options to run solar pump. First is solar power, second is electricity grid and the third is solar battery. In day time your water pump is powered by solar electricity, in nights it is powered by grid and when both (solar power and grid) is not available then it will powered by battery.

On grid solar water pump

In on grid solar system, your water pump will be powered by solar panel. In case when the solar panel is generating more power than water pump’s consumption, then the excess power will automatically exported to grid via net-metering and government will also adjust it in your next bill.

Solar Water Pump Price

AC and DC solar pump price starts from 1 HP @ Rs. 85000 to 10 HP @ 5.9 Lakh depending on rating, type, technology and brand. Subsidy schemes and policies of solar pump are different for every state in India.

Solar Pump Model Selling price
1 HP Solar Pump Set Rs. 84000
2 HP Solar Pump Set Rs. 145000
3 HP Solar Pump Set Rs. 195000
5 HP Solar Pump Set Rs. 290000
7.5 HP Solar Pump Set Rs. 475000
10 HP Solar Pump Set Rs. 585000

Get Latest PriceAll price are negotiable.

1HP Solar Water Pump

Particular Description
Solar Pump 1 HP
Solar Pump Type DC Submersible
Pump Head 29-46 Meter
Solar Panel 900 watt
Controller 1 Set
Open circuit voltage 90-140 V DC
Maximum peak voltage 110 V DC
Maximum Input Current 8.2 Amps
Output voltage 30-85 V
Input power 900 W DC
Protections Over current, over & low voltage, dry run, overflow etc.
Accessories Structure, wires, nut bolt etc.
Discharge 6200 – 38400 Liters per day.
Warranty 5 years for complete system and 25 years for solar panel.
Delivery 5-7 days
Price Rs. 84000 included installation.

This is the complete 1HP Solar Power Pump with all accessories as per site.

1 hp solar water submersible pump

1 hp solar water submersible pump

Other models of 1HP Solar Water Pump are also available. Read more about:

1 HP Solar Pump

You can place order online for 1HP Solar Power Pump with or without installation:

Order Solar Online

Looking for less price?

Get Latest Price



2HP Solar Water Pump

Particular Description
Solar Pump 2 HP
Solar Pump Type DC Submersible
Pump Head 49-86 Meter
Solar Panel 1800 watt
Controller 1 Set
Open circuit voltage 90-140 V DC
Maximum peak voltage 110 V DC
Maximum Input Current 16 Amps
Output voltage 30-85 V
Input power 1800 W DC
Protection Over current, over & low voltage, dry run, overflow etc.
Accessories Structure, wires, nut bolt etc.
Discharge 12000 – 40000 Liters per day.
Warranty 5 years for complete system and 25 years for solar panel.
Delivery 5-7 days
Price Rs. 145000 included installation.

This is the complete 2HP Solar Power Pump with all accessories as per site.

2 HP Solar water submersible pump price in India

2 HP Solar water submersible pump

Other models of 2HP Solar Water Pump are also available. Read more about:

2 HP Solar Pump

You can place order online for 2HP Solar Power Pump with or without installation:

Order Solar Online

Looking for less price?

Get Latest Price

3HP Solar Water Pump

Particular Description
Solar Pump 3 HP
Solar Pump Type DC Submersible
Pump Head 59-89 Meter
Solar Panel 3 kilowatt
Controller 1 Set
Open circuit voltage 90-140 V DC
Maximum peak voltage 110 V DC
Maximum Input Current 24 Amps
Output voltage 30-85 V
Input power 3000 W DC
Protection Over current, over & low voltage, dry run, overflow etc.
Accessories Structure, wires, nut bolt etc.
Discharge 25000 – 60000 Liters per day.
Warranty 5 years for complete system and 25 years for solar panel.
Delivery 5-7 days
Price Rs. 195000 included installation.

This is the complete 3HP Solar Power Pump with all accessories as per site.

2 HP Solar water submersible pump price in India

2 HP Solar water submersible pump

Other models of 3HP Solar Water Pump are also available. Read more about:

3 HP Solar Pump

You can place order online for 3HP Solar Power Pump with or without installation:

Order Solar Online

Looking for less price?

Get Latest Price

5HP Solar Water Pump

Particular Description
Solar Pump 5 HP
Solar Pump Type DC Submersible
Pump Head 59-119 Meter
Solar Panel 5 kilowatt
Controller 1 Set
Open circuit voltage 90-140 V DC
Maximum peak voltage 110 V DC
Maximum Input Current 40 Amps
Output voltage 30-85 V
Input power 3000 W DC
Protection Over current, over & low voltage, dry run, overflow etc.
Accessories Structure, wires, nut bolt etc.
Discharge 45000 – 100000 Liters per day.
Warranty 5 years for complete system and 25 years for solar panel.
Delivery 5-7 days
Price Rs. 285000 included installation.

This is the complete 5HP Solar Power Pump with all accessories as per site.

5 HP Solar water submersible pump

5 HP Solar water submersible pump

Other models of 5HP Solar Water Pump are also available. Read more about:

5 HP Solar Pump

You can place order online for 5HP Solar Power Pump with or without installation:

Order Solar Online

Looking for less price?

Get Latest Price

10HP Solar Water Pump

Particular Description
Solar Pump 10 HP
Solar Pump Type DC Submersible
Pump Head 59-119 Meter
Solar Panel 10 kilowatt
Controller 1 Set
Open circuit voltage 90-140 V DC
Maximum peak voltage 110 V DC
Maximum Input Current 40 Amps
Output voltage 30-85 V
Input power 10000 W DC
Protection Over current, over & low voltage, dry run, overflow etc.
Accessories Structure, wires, nut bolt etc.
Discharge 120000 – 200000 Liters per day.
Warranty 5 years for complete system and 25 years for solar panel.
Delivery 5-7 days
Price Rs. 580000 included installation.

This is the complete 10HP Solar Power Pump with all accessories as per site.

10 HP Solar water submersible pump

10 HP Solar water submersible pump

Other models of 10HP Solar Water Pump are also available. Read more about:

10 HP Solar Pump

You can place order online for 10HP Solar Power Pump with or without installation:

Order Solar Online

Looking for less price?

Get Latest Price

Advantage of Solar Pump

  • Up to 90% government subsidy on solar pump.
  • Low maintenance because once installed it does not incur the recurring cost.
  • Do not require any fuel or electricity to operate.
  • Stand alone pumping system and does not required any grid, batteries.
  • Cannot be affected by power cuts, low voltage, single phase problems or the motor burning.
  • Solar Pump can be installed in rural areas where electricity is not available.
  • No lubricants are used for operation. So, no chances of soil contamination.
  • Easy to install and operate.
  • An investment for 25-30 years.

Subsidy on Solar Pumps

Government of India (MNRE) providing upto 90% subsidy on solar water pump. This scheme is for farmers only.  You can contact your state solar department or contact us for more detail about subsidy.

Solar Pump Manufacturers

Tata Power Solar pump, Shakti Solar Pump, Jain Irrigation Solar Pump, KSB Solar Pump, CRI Solar Pump, Falcon Solar Pump, Texmo Solar Pump, Kirloskar Solar Pump, KBL Solar Pump, Crompton Greaves Solar Pump, Lubi Solar Pump, Oswal Solar Pump, Grundfos Solar Pump, Amrut Solar Pump etc. are the solar water pump manufacturer in Inida.
