Meticulously designed by pioneers for remarkable results

Femoral Component

Material: Co-Cr-Mo alloy cast and primary finish from orchid (UK).


Reduced anterior flange
Deeper patellar groove
Enhanced cam & spine design
The reduced radius of curvature of posterior condyle for increased flexion
Bone sparing notch cut design
Highly polished surface
Available in 8 sizes

sizes


tibial tray


Tibial Tray

Material: Co-Cr-Mo alloy cast and primary finish from orchid (UK).


Dovetail locking mechanism
Continuous peripheral rim
Highly polished tibial tray to reduce the backside wear rate
Cement pockets for optimum fixation
Available in 7 sizes




Tibial Insert

Material: UHMWPE imported from north plastics (UK).


Deep dish design
Proportionate bearing surface for large contact area
Deeper anterior cut-out
Enhanced PS cam/spine design

tibial insert





Patella

Material: UHMWPE imported from north plastics (UK).


Dome-shaped
3 pegs for optimum fixation
Available in 6 sizes

patella size


tibal extnsion rod


Tibial Extension Rod

Material: Co-Cr-Mo alloy cast and primary finish from orchid (UK).


Hex stem design
Rounded distal end
Available in 9 sizes

tibal extnsion rod size


femoral sizer



The single instrument for anterior & posterior referencing
Whiteside line tracking is possible through the slot provided on the slider
Epicondylar axis tracking possible
Better angular control as linear motion converted to angular motion
