Hastelloy B2 Threaded Forged Fittings Manufacturer in India

sachiya steel

Sachiya Steel International is one of the Leading Manufacturer And Exporter Hastelloy B2 Threaded Forged Fittings, which are made in cohesion with the universally defined quality standards and norms. Due to the presence of high molybdenum content, our Hastelloy B2 Forged Threaded Elbow Fittings (UNS N10665) is expensive. These Hastelloy B2 Forged Threaded Tee Fitting is one of the most popular nickel steel alloys for a reason. Our Hastelloy B2 Forged Threaded Cross Fitting provides resistance to pure sulfuric acid and a number of non – oxidizing acids. These Hastelloy B2 Forged Threaded Cap Fitting can be used in the as-welded condition because it resists the formation of grain – boundary carbide precipitates in the weld heat – affected zone.

Our Hastelloy B2 Forged Threaded Bend Fitting with restricted chemistry can be used in the welded condition and is less susceptible to SCC under many conditions. Meanwhile, our Hastelloy B2 Forged Threaded Coupling Fittings are also being offered in customized sizes and shapes to our customers. These Hastelloy B2 Forged Threaded Union Fittings prevents carburization and suffixation at the elevated temperatures.

Our Hastelloy B2 Forged Threaded Bushing Fitting suitably prevents the development of grain boundary precipitates in the weld heated region and is easily weldable by gas tungsten arc, gas metal arc or shielded metal welding methods. These Hastelloy B2 Forged Threaded Plug Fittings is also resistant to severe corrosion caused by metal chlorides in the boilers containing municipal solid waste.

Hastelloy B2 Threaded Fittings Specifications
Specifications : ASTM B564 & ASME B564
Size : 1/8” NB to 4” NB (Socket weld & Screwed-Threaded)
: ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Class : 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS
Type : Threaded Fittings


Hastelloy B2 Forged Threaded Fittings Chemical Composition


Grade C Mn Si S Co Ni Cr Fe Mo P
B2 0.01 max 1.00 max 0.08 max 0.03 max 2.50 max 50.99 min* 14.50 – 16.50 4.00 – 7.00 15.0 – 17.0 0.04 max


Hastelloy B2 Threaded Fitting Mechanical Properties


Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
8.89 g/cm3 1370 °C (2500 °F) Psi – 1,15,000 , MPa – 790 Psi – 52000 , MPa – 355 40 %


Equivalent Grades for B2 Hastelloy Forged Threaded Fittings
B2 2.4617 N10665 NW 0276 ХН65МВУ NiMo16Cr15W ЭП760


Hastelloy B2 Forged Threaded Fittings Application Industries


  • Off-Shore Oil Drilling Companies
  • Power Generation
  • Petrochemicals
  • Gas Processing
  • Specialty Chemicals
  • Pharmaceuticals
  • Pharmaceutical Equipment
  • Chemical Equipment
  • Sea Water Equipment
  • Heat Exchangers
  • Condensers
  • Pulp and Paper Industry

About Us:

Sachiya Steel International are manufacturers & exporters of Pipes,Tubes ,Pipe Fitting, Fasteners.

Sachiya Steel International is an internationally acclaimed Pipes And Tubes manufacturing company that exports to more than 90 countries worldwide. We export our high-quality fasteners in Saudi Arabia, Oman, UAE, Dubai, Kuwait, Qatar, Mexico, USA, Malaysia, Iran and many other countries.
