The Saw Chain Guide Bar

avatar
sawchainguide

The Saw Chain Guide Bar is designed to provide a steady surface for the saw chain. This piece of equipment is often mounted on a saw bench. The studs on the guide bar are designed to provide resistance against the saw chain's upward movement. The mounting studs also allow for drooping. The jaws on the guide bar engage the periphery of the stud 24 at about one-third of its distance and the apex.


The Saw Chain Guide Bar is an important part of your chainsaw. A proper fit between the chain and the guide bar will ensure that your saw chain runs smoothly and efficiently. While the guide bar does not replace the chain itself, it does protect the saw from being damaged by sagging. If you have this bar and want to ensure its proper fit, you can visit Ace and purchase the replacement part.



To determine which guide bar size will fit your chainsaw, measure the pitch of the chain. Measure the distance between three rivets and divide that by two. The result is the chain saw chain guide bar size. To find the chainsaw chain guide bar size, you can either refer to the chain saw manual or use a vernier caliper to measure the drive links' thickness. Remember that you should never cut yourself or your chain if you aren't careful. Click for info https://ptmi.net/


A saw chain is mounted on the chain saw by mounting nuts 26, 28, and a saw chain. The guide bar then slides axially rearward between the saw chain and drive sprocket. During this process, the saw chain is entrained around the drive sprocket 14 using slot 20 and the loosened nuts. To tension the saw chain, you need to adjust the saw chain.
