Types of Electromechanical Devices and Connector Accessories

Electromechanical Devices are devices that use electricity to move parts. These devices can be anything from an electric motor to an electric typewriter. Modern electromechanical systems use integrated circuits to protect moving parts and resist wear and tear. Electromechanical devices are used in almost everything from printers and computers to disk drives, keyboards, and mice.

Audio Components

Electromechanical devices are used to generate sound waves and convert them to electrical signals. They may also be used to convert air pressure into an electrical signal. Some audio equipment can even reproduce the volume of sound.

There are many types of transducers for audio components. Some are used in both directions, while others are used only in one direction. When selecting a transducer, consider the cost, directional characteristics, linearity of frequency response, and durability.


Encoders are devices that provide feedback on the position and speed of an electromechanical device. These devices may be in the form of a rotary encoder or a linear encoder. They are installed on a robot, railway vehicle, or other device and provide feedback on the position of the electromechanical device. An encoder can also be used as a diagnostic tool to determine whether the device is operating properly or not.

Resolution is the number of complete cycles produced on a single channel within a revolution of the encoder shaft. It depends on the type of encoding disc and the rigidity of the mechanical assembly. In direct-read encoders, the resolution is defined by the number of slots and lines on the optical disc. Too many lines or slots reduce the amount of light that passes through the disc and can produce crosstalk and poor signal strength.

Mechanical Power Transmission

In some embodiments of the invention, the electromechanical power transmission system of a vehicle is controlled by an electronic control unit. This unit receives a signal from the drive system, the power take-off unit, and other signal-producing elements of the vehicle. The signal indicates that the power take-off unit and shaft are about to engage.

The components of mechanical power transmission include shaft couplings, gears, chains, sprockets, belts, sheaves, and other products that can transmit mechanical energy. These components come in thousands of different designs and are made of a variety of materials. Shaft couplings, for example, join two shafts together, reducing slippage. They also help transform rotational motion from the motor to linear reciprocating motion.

Electromechanical Switches

Electromechanical switches are used to control the state of an electrical circuit. They come in different shapes, sizes, actuators, and terminations. These different characteristics affect the way the switch responds to user inputs.

These devices are used to enhance the design of products and services. Depending on the application, they are either surface-mounted, illuminated, or sealed. Custom miniature switches are also available, which feature lever or rocker style switches and a wide range of operating forces.

Electromechanical Switches are generally used in electrical applications, such as in industrial control and home automation. They are extremely reliable and are capable of handling high-frequency currents. Some models can also be equipped with ribbon cable assemblies. In addition to these features, these devices are RoHS and REACH compliant.

Motion Control and Fluid Power

When designing a robotic system, it is critical to select the proper power source. Electric motors are often the first choice, but many manufacturers have yet to consider the benefits of pneumatics or hydraulics for their robotic applications. Both can deliver significant benefits over electromechanical motion. Fluid power is a better choice for robotic systems because it can provide smooth, forgiving motion.

Fluid power is one of the oldest forms of motion control and has been used in a variety of applications including pressing, injection molding, handling, and packaging. Over the years, fluid power has evolved to offer servo and proportional control and has proven to be cost-effective and flexible. Servo motor technology has since replaced fluid power systems in many applications, but fluid power continues to play an important role in motion control.

Connector Accessories

Connector accessories are designed to help make the most out of a connector. These accessories include QPL and commercial backshells, cable clamps, adapters, and more. They can be customized for each connector pin. In the Component Library of the Routing Library Manager, you can define connector accessories and assign them to connectors. Once you have assigned connector accessories to a connector, you can see them displayed in connector tables and circuit summaries.

Connector accessories come in a variety of sizes and shapes. Usually, the size of the back shell matches the size of the connector shell. Other names for back shells are end bells, strain-relief clamps, and cable clamps. Connector accessories must be chosen with care. For example, some box-mounting receptacles don't have accessory threads while others do. Additionally, some connector accessories have internal and external threads.

Mil-spec connectors are designed to withstand extreme conditions and should be protected by connector accessories. To help seal the connection location from environmental hazards, a cable bushing or mounting bracket with sealing screws can be used. Additionally, a Neoprene bushing can be used to provide additional environmental sealing and protect cable jackets.

Connector Other

Connector Other is a technical term for a connector that is not part of the SAP system. It is a means of connecting external applications with SAP. These connectors can be written in C++, Visual Basic, or ABAP. In addition, these connectors support RFC communication. These connectors can be part of an SAP solution or component.

I/O Connector

The I/O Connector is a common component in industrial communication systems, motion applications, and drive systems. This connector is highly reliable, compact, and offers secure locking. It can also withstand harsh conditions. In order to find the best I/O connector for your specific application, it's important to understand how it will be used and its specific needs.

TE Connectivity's CeeLok FAS-X connector is one of the smallest field terminable I/O connectors on the market today. It supports 10Gbps data delivery and features an aluminum or composite shell, optimized shielding, and proven gold-plated AS39029 crimp contacts. Moreover, its X-pin configuration delivers high-speed performance and virtually eliminates crosstalk, even in harsh environments.

Wire and PCB Connector

Wire and PCB connectors are among the most common types of connectors used in modern electronics. They have a variety of features and can be used in a variety of applications. Some models feature low-profile mating for applications that require minimal space.

Others have locking mechanisms like friction locks or snap-fit connections to ensure that the wire is held securely in the socket. Many of these connectors are surface-mounted while others have pins that go through the board.

Wire-to-board connectors offer reliable, low-cost solutions for power and signal transfer. They are often used in automotive, lighting, and industrial applications.

However, they can be difficult to assemble. For this reason, there are different wire-to-board connector styles and sizes. If you're designing a device with multiple circuit boards and need a low-profile connector, look for a wire-to-board connector that is compatible with automated surface mount assembly.

Wire-to-PCB connectors are a great option for connecting two printed circuit boards without the need for additional wiring. They come in different types and sizes and are commonly used in electronics that require a simple connection.
