Gloss testing is an important aspect of determining the quality of the material. This ensures the ability of a surface to reflect light in a specular (mirror-like) manner. In many industries, including automotive, construction, and other manufacturing industries, the gloss level of painted surfaces is an important quality control parameter. Thus, testing is an important part of manufacturing and ensures that an accurate product will be delivered to the customers. We at Presto have come up with a gloss meter, an accurate lab testing instrument that is used to test the glossiness of the surface. Presto is an authorized dealer of this quality testing equipment and ensures that the glossiness of the surface of the materials will be tested easily.
In this blog, we will discuss brief information about the gloss meter triangle and how this quality lab testing equipment is used to determine the glossiness of particular surfaces appropriately. So, let us get started!
Test the glossiness of the surface with ASTM D523 standardized gloss meter
When it comes to materials, glossiness is often used as a measure of how well the material reflects light. A high-gloss material will reflect the lightest, while a low-gloss material will absorb more light. Glossiness can be affected by a number of factors, including the type of material, the surface finish, and the angle of incident light.
Thus, with the use of a gloss testing instrument, one can accurately test the glossiness of the surface and ensure that quality materials will be delivered. The Gloss Meter Tri-angle is used to determine the gloss of a particular surface appropriately and also ascertain the amount of reflected light.
The Paint Gloss Meter is available in different geometries depending upon the type of surface to fulfill the testing requirements of a vast number of customers.
This quality testing equipment has been made in accordance with industrial standards like ISO2813, GB/T 9754, ASTM D523, and ASTM D2457. With the help of this testing instrument, you can easily find the correlation between shining and visual gloss when the sample is placed on a flat surface.
Features of gloss meter triangle
The paint gloss meter is a compact testing instrument that has been designed to test the glossiness of the surface with ease. This quality testing equipment has been equipped with high-quality features that include:
- The instrument is compact, sensitive, and highly portable in nature.
- The testing device measures the whiteness, shine, or brightness of various materials such as plastics, opaque glasses, ceramics, etc.
- It is featured with 20, 60, and 85-degree angles.
- Easy to operate.
- It is designed with user-friendly features
Technical specifications of gloss meter
- Measuring Area (In mm): 85°: 5x36mm, 60°: 9x15mm, 20°: 10x10mm.
- Division value: 0.1 GU
- Measuring Range: 20°:0~1000GU, 60°:0~1000GU, 85°:0~160GU
- Measurement Units of Gloss:
- Range of the Device – 0-10GU, 10-100GU, 100-1000GU
- Reproducibility of the Device – ± 0.2GU, ± 0.5GU, ± 0.5%GU
- Repeatability of the Device – ± 0.1GU, ± 0.2GU, ± 0.2%GU
- Measurement Standard: JJG696 First class Gloss Meter working requirement
- Chromaticity Corresponding: CIE 1931(2°) under CIE C light source
- Standard Accessories: Power Adapter, User Manual, USB cable, Calibration Plate, and software CD (except basic model)
- Different geometry degree measurement is also available.
With these high-quality features and technical specifications, one can easily conduct glossiness tests on the materials and measure the specular reflection of painted surfaces. Now, let us understand the working of this quality testing equipment.
Benefits of testing the glossiness of the surfaces with Gloss meter triangle
The gloss meter for printing industry is a widely used instrument for measuring the glossiness of painted surfaces. It is a portable, handheld device that can provide accurate and reliable measurements of surface gloss in a matter of seconds. Some of the benefits of using a Presto gloss meter include:
- Precision and accuracy: The gloss meter provides precise and accurate measurements of surface gloss, which helps to ensure that painted surfaces meet the required specifications and standards.
- Non-destructive testing: The gloss meter is a non-destructive testing instrument, which means it does not damage the surface being tested. This is particularly important for high-value items, such as automobiles or electronic equipment, where surface damage can reduce their value.
- Easy to use: The gloss meter is designed to be easy to use, with a user-friendly interface and simple operation. This means that even non-technical personnel can use it with minimal training.
- Portability: The gloss meter is a portable device that can be easily carried to different locations for testing purposes. This makes it an ideal instrument for quality control inspections, both in the field and in the laboratory.
- Cost-effective: The gloss meter tri-angle is a cost-effective instrument that provides accurate and reliable measurements of surface gloss. This makes it a valuable investment for manufacturers, as it helps to reduce production costs and improve product quality.
Overall, the use of a Presto gloss meter can help to ensure that painted surfaces meet the desired gloss level and consistency, which is important for achieving a high-quality finish and maintaining customer satisfaction.
You can even take a free sample testing session for the use of this quality testing equipment by giving us a call at +91-9210903903 or emailing us at info@prestogroup.com to know about gloss meter price. Our team of technical experts will consult you regarding all your needs and queries.
