Vibratory Sieve Shaker VS1100

Vibratory Sieve Shaker VS1100 is a highly efficient and versatile instrument designed for precise and reliable particle size analysis across a wide range of applications. It is ideal for sieving both organic and inorganic materials such as sand, rocks, soil, clay, granite, feldspar, coal, powders, grains, seeds, and many other solid particles. Whether used in research laboratories, quality control departments, or production environments, the VS1100 delivers consistent and reproducible results.

The machine is equipped with an advanced electromagnetic drive that ensures uniform, powerful, and maintenance-free operation. Its 3D sieving motion—a unique combination of horizontal and vertical movements—promotes faster particle separation, improves efficiency, and ensures accurate classification even in challenging samples.

The VS1100 features a 5” full-colour LED touchscreen that allows intuitive control and display of all sieving parameters. Users can digitally set and store values for amplitude (0.2 to 3.0 mm), sieving time (01–999 minutes), interval time, and pause time (01–99 seconds). It supports both dry and wet sieving methods, offering exceptional flexibility for a wide range of testing requirements.

Compatible with ASTM/ISO sieves in diameters of 100, 150, 200, and 203 mm (8”), with sieve heights of 25 or 50 mm, the VS1100 supports up to 17 or 9 fractions depending on the configuration. It handles a measuring range from 20 μm to 25 mm, making it suitable for both fine and coarse materials.

Additional features include the use of sieving aids in various materials like agate, rubber, and nylon, depending on the mesh size and sample type, ensuring optimal separation efficiency. The unit operates at low noise levels (≤ 60 dB) and requires minimal maintenance, ensuring long-term, trouble-free use.

The shaker can store up to 9 user-defined SOPs (Standard Operating Procedures), enabling quick setup and consistent test conditions. It is ISO, CE, and IP30 certified, meeting global quality and safety standards.

For data-driven labs, the VS1100 can be connected to a PC via Smart Screen Software, allowing advanced data processing, screening evaluation, result documentation, and system control directly from the computer.

With its cutting-edge features and robust design, the Vibratory Sieve Shaker VS1100 is a perfect solution for precise particle analysis in industries such as mining, agriculture, construction, pharmaceuticals, food processing, and many more.

Visit www.technovalue.in for detailed product specifications, brochures, and quotation requests.
