The Ideal PTRO Technology by Rochem India

The Plate and Tube membrane in wastewater filtration process incorporates Plate and Tube Reverse Osmosis technology. It is specially designed for difficult and high concentration wastewater treatment with exceptional stability and high performance. The anatomy of PTRO membrane makes the wastewater treatment highly efficient with its plate and frame structure.

The module with multiple circular membrane cushions within the structure of ABS plastic plates forms a sandwich with a permeate carrier passage for the purified water. The feed flows over each subsequent membrane cushion contained within the hydraulic plate structure and exits the last chamber as concentrate. The purified water or permeate is collected from each membrane cushion. Hence there are two final outlets from each individual module – one is recyclable permeate and the other being RO reject or the concentrate.

An Efficient Solution by Rochem India

The highly efficient PT Module Membrane Systems by Rochem India addresses several challenges faced in the treatment of wastewater and its conversion to reusable quality water.

The advantages of our PT Module Membrane Systems technology has a long list that includes:

  1. Simplified & lower pretreatment
  2. Ability to handle higher COD/BOD, SDI, Turbidity streams compared to conventional technologies
  3. Consistent and high recovery rates
  4. High reliability
  5. Consistent high quality permeate
  6. High pressure Plate and Tube RO designs for further recovery from RO reject concentrates
  7. Lesser space requirement

The Plate and Tube RO applications are spread wide and successfully over a range of industries:

  1. Pharmaceutical
  2. Chemical
  3. Textile
  4. Distillery
  5. Tannery
  6. Automobile
  7. Food & Beverage
  8. Steel & Power
  9. Electroplating
  10. Agrochemical
  11. Sewage
  12. Leachate

We offer customized and continuously evolving technology that adapts with the changing needs of the industry and our clientele. Get in touch with us through our mail at [email protected], or leave a message on our social media accounts - Facebook, Instagram and LinkedIn or call us on +91 (022) 6704 9000 for any enquiries and further information.
