In this article I’d like to highlight recent additions to ConstraintLayout in Android Studio 2.3 (Beta): chains and ratios, as well as give some general ConstraintLayout tips and tricks.
It lets you toggle between three chain modes: Spread, Spread Inside, and Packed Chain.
If you have a Packed chain, you can adjust the horizontal (or vertical) bias to move all elements of the chain left and right (or up and down).
restrict a View to a set width to height ratio, without the overhead of the additional ViewGroup in your hierarchy.
To set a ratio for any view inside a ConstraintLayout:
Make sure at least one of the size constraints is dynamic, i.e.
