Sachiya Steel International is a known manufacturer and exporter of Titanium Gr 2 Angle And Other Titanium Products, which is stronger than Grade 1 and equally corrosion – resistant against most applications. Titanium Grade 2 Angle is least used of the commercially pure titanium grades, but that does not make it any less valuable. Titanium Grade 2 C-Channel can also be easily machined, hot worked and welded, where hot working should be performed between 400 Degree F and 600 Degree F. Titanium Grade 2 Chain is not heat treatable, and is used for condensers & heat exchangers.
Titanium Grade 2 I-Beam is an alpha – beta alloy, which has better response than Ti Grade 5 when heat treating to high strength levels. The oxide scale of Titanium Grade 2 H-Beam, in turn, presents a very good protective layer, preventing bulk from oxidation. The oxidized layer of Titanium Grade 2 T-Beam provides a better protection than the use of argon or high vacuum.
Grade 2 Titanium Angle has physical and mechanical properties equivalent to CP3 titanium. The corrosion resistance of Grade 2 Titanium Chain is based on the presence of a stable, continuous, tightly adherent oxide layer. Grade 2 Titanium C-Channel also offers a higher strength – to – weight ratio and increased corrosion resistance compared to the stainless steel alloys, thus making it an attractive choice for medical applications. Grade 2 Titanium I-Beam possesses good weldability, strength, ductility and formability.
Titanium Grade 2 Angle, Channel, Beam, Chain Specifications |
||
Specifications | : | ASTM B348 / ASME B348 |
Dimensions | : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
Titanium Gr 2 Angle |
: | 5mm to 9mm |
Titanium Gr 2 Channel |
: | 40mm*20mm~300mm*300mm |
Titanium Gr 2 Beam | : | 3″ thru 12.31″ |
Titanium Gr 2 Chain |
: | 1/8 inch – 1/2 inch Diameter |
Thickness |
: | 3.0mm – 120mm |
Length | : | 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes |
Type | : | Angle, C Channel, U Channel, H Beam, I Beam, T Beam, W Beam, Chain |
Grade 2 Titanium Angle, Channel, Beam, Chain Chemical Composition
Grade | C | H | N | O | Ti | Fe |
Titanium Grade 2 | 0.1 max | 0.015 max | 0.3 max | 0.025 max | 99.2 min | 0.3 max |
Titanium Gr 2 Angle, Channel, Beam, Chain Mechanical Properties
Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
4.5 g/cm3 | 1665 °C (3030 °F) | Psi – 49900 , MPa – 344 | Psi – 39900 , MPa – 275 | 20 % |
Equivalent Grades for Grade 2 Titanium Angle, Channel, Beam, Chain
STANDARD | WERKSTOFF NR. | UNS |
Titanium Grade 2 | 3.7035 | R50400 |
Titanium Grade 2 Angle, Channel, Beam, Chain Application Industries
- Off-Shore Oil Drilling Companies
- Power Generation
- Petrochemicals
- Specialty Chemicals
- Pharmaceuticals
- Pharmaceutical Equipment
- Chemical Equipment
- Sea Water Equipment
- Heat Exchangers
- Condensers
- Pulp and Paper Industry
