Introduction :
Solenoid valves are essential components used in various industries and applications such as fluid control, automation, and HVAC systems. They are used to control the flow of fluids or gases by opening or closing the valve through the application of an electric current.
Application requirements : The first step in selecting a solenoid valve is to identify the application requirements. This includes understanding the type of fluid or gas being controlled, the pressure and temperature range, the flow rate, and the environment in which the valve will be operating. For example, if the fluid being controlled is corrosive, it is essential to select a solenoid valve that is resistant to corrosion. Similarly, if the valve is being used in a high-pressure application, it is important to choose a valve that can handle the required pressure range.
Valve type:
There are different types of solenoid valves available, and the selection of the valve type depends on the application requirements. The most common types of solenoid valves include:
2-way valves: These valves have two ports, an inlet, and an outlet, and are used for on-off applications.
3-way valves: These valves have three ports, and are used for diverting or mixing applications.
4-way valves: These valves have four ports, and are used for applications that require both diverting and mixing.
It is important to select the right valve type for the application to ensure optimal performance.
Valve size:
The size of the valve is another important factor to consider when selecting a solenoid valve. The size of the valve is typically determined by the flow rate required for the application. The valve size should be selected to ensure that it can handle the maximum flow rate required.
Material of construction:
The material of construction is also an important consideration when selecting a solenoid valve. The material should be compatible with the fluid or gas being controlled, and should be able to withstand the temperature and pressure range required for the application. Some common materials of construction include brass, stainless steel, and plastic.
Coil type:
The coil is the component of the solenoid valve that produces the electromagnetic force required to open or close the valve. There are two types of coils available - AC and DC. AC coils are used in applications where the valve needs to be opened or closed rapidly, while DC coils are used in applications where the valve needs to be held open or closed for an extended period.
Electrical requirements:
The electrical requirements of the solenoid valve should also be considered when selecting a solenoid valve. This includes the voltage, frequency, and power requirements of the valve. It is important to select a valve that meets the electrical requirements of the application to ensure optimal performance.
Environmental factors:
The environment in which the solenoid valve will be operating should also be considered when selecting a solenoid valve. This includes factors such as temperature, humidity, and vibration. It is important to select a valve that can operate in the environmental conditions present in the application.
Fluid compatibility : The solenoid valve must be compatible with the fluid or gas that will be passing through it. The material of construction should be selected based on the chemical compatibility with the fluid or gas. For example, solenoid valves made from brass or stainless steel are commonly used for water or air applications, while solenoid valves made from materials like PVC or PVDF may be used for chemical applications.
Flow rate : The flow rate through the solenoid valve is dependent on various factors such as the size of the valve, the pressure drop, and the viscosity of the fluid or gas. It is important to select a solenoid valve with a flow rate that is suitable for the application.
Operating temperature : The solenoid valve must be able to operate at the desired temperature range for the application. Solenoid valves may experience a decrease in performance or even failure if they are operated outside of their temperature limits.
Power consumption : The power consumption of the solenoid valve should be considered, especially in applications where energy efficiency is important. High power consumption can lead to increased operating costs and decreased energy efficiency.
Installation and maintenance : The ease of installation and maintenance should also be considered. Solenoid valves that are difficult to install or maintain can increase downtime and maintenance costs.
How Aira Euro can assist in selecting the perfect solenoid valve:
At Aira Euro, we offer a wide range of solenoid valves that can be customized to meet the specific requirements of your application. We work closely with our clients to understand their application requirements and provide them with the best possible solution. Our solenoid valves are manufactured using high-quality materials and are designed to In addition to our standard product range, we also offer custom solenoid valves that can be designed to meet your specific requirements. Our team of experts can help you design a solenoid valve that is tailored to your application, ensuring that you get the best possible solution.
We also offer technical support and assistance to our clients throughout the selection and installation process. Our team of experts can help you select the right solenoid valve for your application, and provide you with guidance on installation and maintenance.
Valve actuation time: The actuation time of the solenoid valve refers to the time it takes for the valve to open or close when an electric current is applied. The actuation time can vary depending on the type of valve, coil type, and the electrical signal being used. In applications where a fast response time is required, it is important to select a solenoid valve with a short actuation time.
Pressure drop: The pressure drop across the solenoid valve is the difference in pressure between the inlet and outlet ports when the valve is open. The pressure drop can affect the flow rate and efficiency of the system. It is important to select a solenoid valve with a pressure drop that is suitable for the application.
Leakage rate: The leakage rate of the solenoid valve refers to the amount of fluid or gas that can leak through the valve when it is closed. In applications where tight shut-off is required, it is important to select a solenoid valve with a low leakage rate.
Certification: Depending on the application and industry, it may be necessary to select a solenoid valve that is certified by a specific organization or regulatory body. For example, solenoid valves used in food processing or pharmaceutical industries may need to be certified by the FDA or other regulatory bodies.
Conclusion : selecting the right solenoid valve for a specific application requires considering various factors, including fluid compatibility, flow rate, operating temperature, power consumption, and installation and maintenance requirements. At Aira Euro, we can help you navigate these factors and select the perfect solenoid valve for your application. Contact us today to learn more about how we can assist you in selecting the right solenoid valve for your application.
The report "Solenoid valve Market by Body Material (Stainless Steel, Brass, Aluminum, and Plastic), Valve Design (2-way, 3-way, 4-way, and 5-way), Industry, and Geography - Global Forecast to 2022", The solenoid valve market is expected to reach USD 4.41 Billion by 2022, at a CAGR of 3.54% between 2016 and 2022.
This market registered a shipment of 12.94 Million units in 2015 and is expected to reach 20.29 Million units by 2022, at a CAGR of 6.35% between 2016 and 2022.
The major factors driving the growth of this market include the growing investments in various industries across developing economies such as China and India and greater preference for increasing process automation worldwide thereby decreasing production costs.Get PDF Brochure: https://www.marketsandmarkets.com/requestsampleNew.asp?id=26318408The chemical & petrochemical industry in the solenoid valve market held the largest share in 2015The solenoid valve market on the basis of industry vertical has been segmented into oil & gas, chemical & petrochemical, water & wastewater, food & beverages, pharmaceuticals, power generation, automobile, medical, and others.
Among the various industries considered for the study, the chemical & petrochemical industry held the largest share in 2015.
This market is expected to grow at a significant rate between 2016 and 2022, driven by the growing installations of solenoid valves in different phases of oil & gas extraction processes.
The continuous retrofit works in this industry would significantly contribute to this market.The market for 3-way solenoid valves is expected to grow rapidly during the forecast periodThe solenoid valve market based on valve design type has been segmented into 2-way, 3-way, and 4-way solenoid valves.
In this report, our team offers a comprehensive analysis of Solenoid Valve market, SWOT analysis of the most prominent players in this landscape.
Along with an industrial chain, market statistics in terms of revenue, sales, price, capacity, regional market analysis, segment-wise data, and market forecast information are offered in the full study, etc.
Download Free Sample Report @ https://www.radiantinsights.com/research/global-solenoid-valve-market-2020-2026/request-sample This report focuses on top manufacturers in global market, Involved the assessment of Sales, price, revenue and market share for each manufacturer, covering • ASCO• Kendrion• Danfoss• Parker• Burkert• SMC• Norgren• CKD• CEME• Sirai• Saginomiya• ODE• Takasago Electric• YPC• PRO UNI-D• Airtac• Zhejiang Sanhua On the basis of product, this report displays the Sales, revenue, price, market share and growth rate of each type, primarily split into • Direct-Acting Solenoid Valve• Sub-Step Direct-Acting Solenoid Valve• Pilot-Type Solenoid Valve By Application, this report focuses on Sales, Market share and Growth Rate of each application, can be divided into • Home appliances• Automobile• Industrial• Machinery Industry• Agriculture• Others By Regions, this report splits global market into several key regions, with Sales, Revenue, Price and Gross Margin market share of top players in these regions, from 2014 to 2026 (forecast), like • China• USA• Europe• Japan• Korea• India• Southeast Asia• South America Browse Full Research Report with TOC @ https://www.radiantinsights.com/research/global-solenoid-valve-market-2020-2026 Table of Contents Global Solenoid Valve Market Professional Survey Report 2019 1 Report Overview1.1 Definition and Specification1.2 Manufacturers and Region Overview1.2.1 Manufacturers Overview1.2.2 Regions Overview1.3 Type Overview1.3.1 Direct-Acting Solenoid Valve1.3.2 Sub-Step Direct-Acting Solenoid Valve1.3.3 Pilot-Type Solenoid Valve1.4 Application Overview1.4.1 Home appliances1.4.2 Automobile1.4.3 Industrial1.4.4 Machinery Industry1.4.5 Agriculture1.4.6 Others1.5 Industrial Chain1.5.1 Solenoid Valve Industrial Chain1.5.2 Upstream1.5.3 Downstream 2.1 The Overall Market Performance(Volume)2.1.1 Direct-Acting Solenoid Valve2.1.2 Sub-Step Direct-Acting Solenoid Valve2.1.3 Pilot-Type Solenoid Valve2.2 The Overall Market Performance(Value)2.2.1 Direct-Acting Solenoid Valve2.2.2 Sub-Step Direct-Acting Solenoid Valve2.2.3 Pilot-Type Solenoid Valve 3 Global Solenoid Valve Market Assessment by Application3.1 Overall Market Performance (Volume)3.2 Home appliances3.3 Automobile3.4 Industrial3.5 Machinery Industry3.6 Agriculture3.7 Others 4 Competitive Analysis4.1 ASCO4.1.1 ASCO Profiles4.1.2 ASCO Product Information4.1.3 ASCO Solenoid Valve Business Performance4.1.4 SWOT Analysis4.2 Kendrion4.2.1 Kendrion Profiles4.2.2 Kendrion Product Information4.2.3 Kendrion Solenoid Valve Business Performance4.2.4 SWOT Analysis4.3 Danfoss4.3.1 Danfoss Profiles4.3.2 Danfoss Product Information4.3.3 Danfoss Solenoid Valve Business Performance4.3.4 SWOT Analysis4.4 Parker4.4.1 Parker Profiles4.4.2 Parker Product Information4.4.3 Parker Solenoid Valve Business Performance4.4.4 SWOT Analysis4.5 Burkert4.5.1 Burkert Profiles4.5.2 Burkert Product Information4.5.3 Burkert Solenoid Valve Business Performance4.5.4 SWOT Analysis Continued… Read all Reports of this category @ https://www.radiantinsights.com/catalog/equipment About Radiant InsightsRadiant Insights is a platform for companies looking to meet their market research and business intelligence requirements.
It assists and facilitate organizations and individuals procure market research reports, helping them in the decisions making process.
The Organization has a comprehensive collection of reports, covering over 40 key industries and a host of micro markets.
In addition to over extensive database of reports, experienced research coordinators also offer a host of ancillary services such as, research partnerships/ tie-ups and customized research solutions.
Solenoid valve market is advancing constantly and anticipated that would observe huge expansion over the years to come.
Aspects which are driving the expansion of worldwide market are growing employment of solenoid valves into different industrial divisions, bring down the cost of a valve as well as lower power utilization.
Uneven pressure, power failure, the wrong voltage might influence the operation of the solenoid valve in view of which solenoid valves might not open, inconsistent valve sounds while closing and the opening of valve in addition to coil issues in solenoid valves are a few of the basic issues related with solenoid valves.
Thus rising concerns with respects to the plants safety governments of nations for instance the UK, Japan, South Africa and America are ensuring measures to boost the content of the subsisting power plants.For the link of solenoid valves, a variety of wire is utilized by which it has turned out to be hard to interface properly.
Solenoid valves are additionally utilized in automatic irrigation sprinkle system.
Out of every one of these applications, the chemical industry is, for the most part, utilizing, globally.Among the prominent regions, the Western Europe and North America solenoid valve region market are considered to contribute majorly in the worldwide market for solenoid valve over the years to come.Request For TOC: https://www.researchreportinsights.com/report/TOC/120124706/Solenoid-valve-MarketA few of the prominent market players are worldwide solenoid valve market are Danfoss A/S, ASCO Valve, Inc., CKD Corporation, SMC Corporation of America, Christian Bürkert GmbH & Co. KG, IMI plc Company, ODE s.r.l., GSR Ventiltechnik GmbH & Co. KG, KANEKO SANGYO Co., Ltd, TAKASAGO ELECTRIC INDUSTRY CO., LTD., CEME S.p.A., Ningbo mailing pneumatic co., Ltd. and Parker Hannifin Corp. amid others.
