Components of Coaxial Cable
Coaxial cable consists of an inner conductor surrounded by a tubular insulating layer, surrounded by a tubular conducting shield. Traditionally, the inner conductor is a single wire made of copper, the dielectric layer is plastic foam, and the surrounding shield is braided copper or aluminum wire. Modern coaxial cables use different materials such as silver plating for the inner conductor and carbon nanotubes for improved conductivity.
The inner conductor carries the electrical signal being transmitted. It is usually a solid copper wire of a specific gauge ranging from 12 to 22 American Wire Gauge. Stranded wire is not used for the inner conductor due to signal loss issues.
In a Coaxial Cable, surrounding the inner conductor is the dielectric layer, which is typically made of plastic foam to provide insulation and preserve signal integrity. Common foam dielectric materials include polyethylene and a cross-linked polyethylene variant called PEX. The dielectric layer serves to separate and isolate the inner conductor from the outer shield, ensuring that the electrical signals transmitted through the cable are not interfered with and remain clear.
Wrapped around the dielectric is the outer conductor or shield. It serves to confine the electrical field carrying the signal to the inside of the cable. Traditionally this outer shield consists of a mesh of braided copper or aluminum strands. Copper is more commonly used due to its superior conductivity. The braided mesh structure allows the shield to flex with the cable while maintaining coverage.
Applications of Coaxial Cable
Coaxial cable has traditionally found widespread use for cable television signals due to its high bandwidth capabilities. CATV systems utilize coaxial to distribute cable TV signals from the provider to individual houses and buildings. The closed copper shield construction eliminates signal leakage and allows signals to travel for longer distances without degradation.
Coaxial is also used extensively for over-the-air television broadcasts and distribution between towers, transmitters and receivers. Broadcasters value its resistance to external interference and ability to carry high definition television signals. Cellular networks, community antenna television systems, closed-circuit television, and cable Internet all rely on coaxial infrastructure.
Newer applications continue to emerge with technology. Coaxial is integral to emerging 5G wireless networks to connect cellsites and distribute high speed signals. Audio/video installations in homes, businesses and venues use coaxial for signal distribution between devices and displays. CCTV security cameras connected via coax are a familiar sight. Last-mile broadband Internet is also delivered using coaxial in some cases.
Advantages of Coaxial Cable
Several key properties make coaxial cable such an enduring and widely used transmission medium:
- High bandwidth - Modern coaxial can support transmission speeds up to 10Gbit/s or more depending on cable type. This facilitates distribution of high definition signals.
- Low interference susceptibility - The shielded copper construction resists external electrical interference that plagues other cable types. Signals travel cleanly without degradation.
- Long transmission distances - Coaxial retains signal integrity over longer spans than alternative cables before needing signal boosters. Distance potential is hundreds of feet or more depending on frequency.
- Duplex capability - Carrying signals in both directions simultaneously using the same cable. This allows two-way connectivity for services like cable Internet.
- Durability - Coaxial withstands bending, crushing, weather and corrosion better than copper wire alone. Installation is robust and long-lasting in buried outdoor plant applications.
- Cost-effectiveness - Despite initial material costs, coaxial offers low installation and maintenance expenses relative to alternative wired solutions like fiber. Especially for shorter distances.
Disadvantages and Drawbacks
While coaxial maintains a place as a reliable option, some drawbacks have emerged as new technologies rise:
- Lower bandwidth ceiling - The upper bandwidth limit of coaxial is lower than cutting-edge solutions like fiber. Modern high bandwidth applications will max it out.
- Electromagnetic interference susceptibility - Compared to fully shielded twisted pair or fiber, coaxial remains open to some interference that degrades signals over long runs.
- Size and weight - Bundles of coaxial take up more space than lightweight glass fiber. This impacts installation costs especially in congested areas.
- Installation complexity - Troubleshooting faults on large coaxial plants requires more time and expertise than simpler structured cable systems. Repairs also take longer.
- Cost for upgrades - Replacing or upgrading an existing coaxial infrastructure entails considerable teardown and reinstallation expenses. Despite limitations, coaxial cable will continue serving various connectivity needs for the foreseeable future. Its combination of bandwidth capability, longevity and moderate costs maintain relevance even amid fiber expansion. Advanced coaxial designs also push performance to keep up with demand as new applications emerge.
